3. Adjustments
USE AND MAINTENANCE MANUAL CHAPTER 3
ADJUSTMENTSXEF 250 - Rev01 / 2020
54
B
A
3.6 REAR-VIEW MIRRORS
The operations described below apply to both
rearview mirrors.
– Place the vehicle on the kickstand and on a flat and stable
surface.
– Loosen the lock nut “A”, turn the left-hand mirror counter-
clockwise and remove it, then turn the right-hand mirror
clockwise and remove it.
During reassembly, before tightening the nut, check
that the mirror support rod is aligned with the
handlebar.
Rear-view mirror adjustment
To adjust the rear-view mirrors, get on the vehicle in the
driving position and turn the rear-view mirror according to
your needs. It is also possible to adjust the inclination of the
rear-view mirror support rod. To carry out this operation,
loosen the screw “B” and move the support rod sideways.
Adjust and tighten screw “B”.
