Fantic XEF 250 - Right and Left Side Components

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
15
1
20
21 22 23
24 25
18 1917
15
16
Right and left side components
Ref. Component
15 Headlight
16 Radiator
17 Rear brake pedal
18 Inspection window for oil level check
19 Coolant drain bolt
20 Front fork
21 Fuel tank
Ref. Component
22 Air filter
23 Taillight
24 Shift pedal
