Fantic XEF 250 - Electrical

1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
27
1
Electrical
Item Standard Limit
Tensione impianto
12 V –
Ignition system:
Ignition system
Ignition timing (B.T.D.C.)
TCI
7.0–13.0 gradi/2000 giri/min.
–
–
Ignition coil:
Primary coil resistance
Secondary coil resistance
2.16–2.64 
8.64–12.96 
–
–
Spark plug cap:
Resistance
7.50–12.50 k –
Lean angle sensor:
Operating angle 45 ° –
Charging system:
Charging system
Standard output
Stator coil resistance
AC magneto
14.0 V, 10.0 A at 5000 r/min.
0.368–0.552 
–
–
–
Rectifier / regulator:
Regulator type
Regulated voltage (DC)
Single-phase
14.0–14.8 V
–
–
Indicator light:
Fuel level warning light
Engine trouble warning light
1.7 W
1.7 W
–
–
Starter motor:
Brush overall length
Brush spring force
Mica undercut (depth)
7.0 mm (0.28 in)
3.92–5.88 N
(400–600 gf, 14.11–21.17 oz)
–
3.5 mm (0.14 in)
–
1.50 mm (0.06 in)
Fuel injection sensor:
Crankshaft position sensor resistance
Intake air temperature sensor resistance
Intake air temperature sensor resistance
Coolant temperature sensor resistance
Coolant temperature sensor resistance
228–342 
5400–6600  a 0°C
(5400–6600  a 32°F)
289–391  a 80°C
(289–391  a 176°F)
2513–2777  a 20°C
(2513–2777  a 68°F)
210–221  a 100°C
(210–221  a 212°F)
–
–
–
–
–
