13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
26
Item Standard Limit
Slow compression damping:
Unit for adjustment
Adjustment value from the start position
(Soft)
Adjustment value from the start position
(STD)
Adjustment value from the start position
(Hard)
Click
20
8
0
–
–
–
Swingarm:
Swingarm end free play limit (radial)
Swingarm end free play limit (axial)
–
–
1.0 mm (0.04 in)
0.2–0.9 mm (0.01–0.04 in)
Wheel:
Front wheel type
Rear wheel type
Front rim size/material
Rear rim size/material:
Rim runout limit:
Radial
Lateral
Front wheel axle bending limit
Rear wheel axle bending limit
Spoke wheel
Spoke wheel
21 × 1.60/Aluminium
18 × 2.15/Aluminium
–
–
–
–
–
–
–
–
2.0 mm (0.08 in)
2.0 mm (0.08 in)
0.50 mm (0.02 in)
0.50 mm (0.02 in)
Drive chain:
Type
Number of links
Chain slack
Chain length (15 links)
DID520MXV5-114LL
114
58.0–68.0 mm (2.28–2.28 in)
–
–
–
–
239.3 mm (9.42 in)
Front brake:
Front brake lever free play
Disc outside diameter × thickness
Brake disc thickness limit
Brake disc runout limit
(as measured on wheel)
Master cylinder inside diameter
Caliper cylinder inside diameter (Left)
Specified brake fluid
2.7–11.1 mm (0.11–0.44 in)
270.0 × 3.0 mm (10.63 in × 0.12 in)
2.5 mm (0.10 in)
0.15 mm (0.0059)
9.52 mm (0.37 in)
22.65 mm, 22.65 mm (0.89 in, 0.89 in)
DOT 4
–
–
–
1.0 mm (0.04 in)
–
–
Rear brake:
Brake pedal position
Disc outside diameter × thickness
Brake disc thickness limit
Brake disc runout limit
(as measured on wheel)
Master cylinder inside diameter
Caliper cylinder inside diameter
Specified brake fluid
5.0 mm (0.20 in)
245.0 × 4.0 mm (9.65 in × 0.16 in)
3.5 mm (0.14 in)
0.15 mm (0.0059)
11.0 mm (0.43 in)
25.40 mm (1.00 in)
DOT 4
–
–
–
1.0 mm (0.04 in)
–
–
