4. Maintenance
USE AND MAINTENANCE MANUAL CHAPTER 4
MAINTENANCEXEF 250 - Rev01 / 2020
83
4
2
3
1
Wheel check
The following procedure applies to both wheels.
– Place a stand under the engine, lift the wheel and turn
it. Check the centering and alignment of the rim channel
with respect to the wheel hub. If there are any anomalies,
proceed with the correction by pulling the spokes;
– Check that the wheel bearings do not have axial clearance.
If there is, change the bearings.
If there are cracks or splits in the rim channels, it is
necessary to replace them.
Never try to repair the wheel rims.
4.14 BRAKE PADS
Replace the front brake pads
– Remove the pad pin plug “1”;
– Loosen the pad pin “2” then remove the brake calliper “3”
from the fork;
