13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
22
Item
Thread size
Quantity Tightening torque Remarks
Bolt (rear frame cover) (left)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Fuel tank bolt (front side)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Fuel tank bolt (boss)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Fuel tank bolt (rear side) M6 1 9 Nm (0.9 kgf•m, 6.6 lb•ft)
Fuel tank bracket bolt M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Fuel pump bolt
◊
M5 5 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Screw (fuel inlet pipe) M5 2 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)
Bolt (fuel tank cap cover) M6 2 4.0 Nm (0.40 kgf•m, 3.0 lb•ft)
Seat set bracket screw M6 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Seat bolt
◊
M8 2 22 Nm (2.2 kgf•m, 16 lb•ft)
Side cover bolt (left)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Side cover bolt (right)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Air scoop bolt (frame)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Air scoop bolt (fuel tank)
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Air scoop bolt (radiator guard)
◊
M6 4 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Front fender bolt
◊
M6 4 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Rear fender bolt (front side)
◊
M6 4 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Rear fender bolt (rear side)
◊
M6 2 16 Nm (1.6 kgf•m, 12 lb•ft)
Headlight body and headlight stay bolt M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Multi-function meter nut M5 2 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Multi-function meter bracket bolt M6 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Front brake hose guide and head light stay bolt M5 1 3.8 Nm (0.38 kgf•m, 2.8 lb•ft)
Screw (mud flap)
◊
— 2 1.3 Nm (0.13 kgf•m, 0.95 lb•ft)
Frame ground bolt (negative battery lead) M5 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Tip : Lower ring nut
– First, tighten the lower ring nut approximately 38 Nm (3.8 kgf•m, 28 lb•ft) by using the steering nut wrench, then loosen the lower
ring nut one turn.
– Retighten the lower ring nut 7 Nm (0.7 kgf•m, 5.2 lb•ft).
Electrical tightening torques
Item
Thread size
Quantity Tightening torque Remarks
Stator M5 3 10 Nm (1.0 m•kg, 7.4 ft•lb)
Rotor M12 1 65 Nm (6.5 m•kg, 48 ft•lb)
Ignition coil M6 2 7 Nm (0.7 m•kg, 7.2 ft•lb)
