1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
21
1
Item
Thread size
Quantity Tightening torque Remarks
Locknut (front brake lever position) M6 1 5 Nm (0.5 kgf•m, 3.7 lb•ft)
Front brake hose union bolt
◊
M10 2 30 Nm (3.0 kgf•m, 22 lb•ft)
Front brake caliper bolt
◊
M8 2 28 Nm (2.8 kgf•m, 21 lb•ft)
Front brake pad pin M10 1 17 Nm (1.7 kgf•m, 13 lb•ft)
Front brake pad pin plug M10 1 2.5 Nm (0.25 kgf•m, 1.8 lb•ft)
Front brake caliper bleed screw
◊
M8 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Front wheel axle nut
◊
M18 1 115 Nm (11.5 kgf•m, 85 lb•ft)
Front wheel axle pinch bolt
◊
M8 4 21 Nm (2.1 kgf•m, 15 lb•ft)
Front brake disc bolt
◊
M6 6 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Rear brake disc bolt
◊
M6 6 12 Nm (1.2 kgf•m, 8.9 lb•ft)
Footrest bracket bolt M10 4 55 Nm (5.5 kgf•m, 41 lb•ft)
Sidestand bolt M10 1 35 Nm (3.5 kgf•m, 26 lb•ft)
Rear brake pedal bolt
◊
M8 1 26 Nm (2.6 kgf•m, 19 lb•ft)
Rear brake pedal adjusting locknut M6 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Rear brake master cylinder bolt
◊
M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Rear brake master cylinder reservoir cap bolt M4 2 1.5 Nm (0.15 kgf•m, 1.1 lb•ft)
Rear brake hose union bolt
◊
M10 2 30 Nm (3.0 kgf•m, 22 lb•ft)
Rear brake caliper bleed screw
◊
M8 1 6 Nm (0.6 kgf•m, 4.4 lb•ft)
Rear brake pad pin M10 1 17 Nm (1.7 kgf•m, 13 lb•ft)
Rear brake pad pin plug M10 1 2.5 Nm (0.25 kgf•m, 1.8 lb•ft)
Rear wheel axle nut
◊
M20 1 125 Nm (12.5 kgf•m, 92 lb•ft)
Drive chain puller locknut M8 2 21 Nm (2.1 kgf•m, 15 lb•ft)
Rear wheel sprocket nut
◊
M8 6 50 Nm (5.0 kgf•m, 37 lb•ft)
Nipple (spoke)
◊
— 72 2.5 Nm (0.25 kgf•m, 1.8 lb•ft)
Bolt (rear brake disc cover)
◊
M6 2 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Rear brake caliper protector bolt
◊
M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Engine mounting bolt (upper side)
◊
M10 2 45 Nm (4.5 kgf•m, 33 lb•ft)
Engine mounting bolt (front side)
◊
M10 1 55 Nm (5.5 kgf•m, 41 lb•ft)
Engine mounting bolt (lower side)
◊
M10 1 53 Nm (5.3 kgf•m, 39 lb•ft)
Engine bracket bolt (upper side)
◊
M8 4 34 Nm (3.4 kgf•m, 25 lb•ft)
Engine bracket bolt (front side)
◊
M8 4 34 Nm (3.4 kgf•m, 25 lb•ft)
Rear frame bolt
◊
M8 4 38 Nm (3.8 kgf•m, 28 lb•ft)
Engine guard bolt
◊
M6 3 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Pivot shaft nut
◊
M16 1 85 Nm (8.5 kgf•m, 63 lb•ft)
Rear shock absorber assembly upper nut
◊
M10 1 56 Nm (5.6 kgf•m, 41 lb•ft)
Rear shock absorber assembly lower nut
◊
M10 1 53 Nm (5.3 kgf•m, 39 lb•ft)
Locknut (rear shock absorber lock- nut) M60 1 10 Nm (1.0 kgf•m, 7.4 lb•ft)
Relay arm nut (swingarm side)
◊
M14 1 70 Nm (7.0 kgf•m, 52 lb•ft)
Connecting arm nut (relay arm side)
◊
M14 1 80 Nm (8.0 kgf•m, 59 lb•ft)
Connecting arm nut (frame side)
◊
M14 1 80 Nm (8.0 kgf•m, 59 lb•ft)
Brake hose holder screw
◊
M5 4 3.5 Nm (0.35 kgf•m, 2.6 lb•ft)
Drive chain tensioner bolt (upper side) M8 1 16 Nm (1.6 kgf•m, 12 lb•ft)
Drive chain tensioner bolt (lower side) M8 1 16 Nm (1.6 kgf•m, 12 lb•ft)
Bolt (drive chain support) M6 1 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Drive chain support nut M6 2 7 Nm (0.7 kgf•m, 5.2 lb•ft)
Drive chain guide bolt M5 3 4.0 Nm (0.40 kgf•m, 3.0 lb•ft)
