Fargo DTC1000 User Manual

© 2010 HID Global Corporation All rights reserved
DTC1000/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.2)
55
Using the Advanced Settings tab
Setting Option
Resin Heat Adjust
Use this adjustment for Black resin text and barcodes if
they appear faded or too light/dark.
• Maximum Adjustment Range is +/- 100.
(Note: This control can be helpful for fine-tuning the
transfer of resin text and bar codes.)
Head Resistance
This is factory set. If the main board or the Printhead is
replaced then adjust this number.
Locate the Printhead Setting Number on the bottom of the
Printhead.
The number reads R=XXXX.
Head Home Offset
This is a calibration driven value and should not be
adjusted. If the Printhead assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed
unless directed by a technician.)
Head Contact Offset
This is a calibration driven value and should not be
adjusted. If the Printhead assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed
unless directed by a technician.)

Fargo DTC1000 Specifications

General

Product color	Black, Silver
Internal memory	32 MB
Built-in barcodes	-
Total input capacity	100 sheets
Maximum resolution	300 x 300 DPI
Print speed (color)	120 card/h
Print speed (monochrome)	515 card/h
Compatible operating systems	- Windows XP / Vista (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / - Linux
Bundled software	Swift D Embedded Badging Application, ARGO Workbench Diagnosis Utility
Interface	USB
Optional connectivity	Ethernet

Weight and Dimensions

Weight	3400 g
Dimensions (WxDxH)	475 x 234 x 249 mm
