Fargo DTC1000 User Manual

© 2010 HID Global Corporation All rights reserved
DTC1000/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.2)
56
Using the Advanced Settings tab
Setting Option
Erase Heat Offset
Adjust the Erase temperature for the rewriteable cards as
needed.
• Increase the Current Setting to cause more heat to
be used in the erasing process.
OR
• Decrease the Current Setting to cause less heat to be
used in the erasing process.
(Note: Erase Heat Offset provides user ability to control
the Printhead heat level when the Erase Operation is
performed. Appropriate heat levels should be applied for
the proper erase process. This setting should be adjusted
for proper erasure.)
Write Heat Offset
Adjust the Write temperature for the rewriteable cards as
needed.
• Increase the Current Setting to cause more heat to
be used in the printing process of a rewritable card.
OR
• Decrease the Current Setting to cause less heat to be
used in the printing process of a rewritable card.
(Note: Write Heat Offset provides user ability to control
the Printhead heat level when the Write Operation is
performed. Appropriate heat levels should be applied for
the proper writing process.)

Fargo DTC1000 Specifications

General

Product color	Black, Silver
Internal memory	32 MB
Built-in barcodes	-
Total input capacity	100 sheets
Maximum resolution	300 x 300 DPI
Print speed (color)	120 card/h
Print speed (monochrome)	515 card/h
Compatible operating systems	- Windows XP / Vista (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / - Linux
Bundled software	Swift D Embedded Badging Application, ARGO Workbench Diagnosis Utility
Interface	USB
Optional connectivity	Ethernet

Weight and Dimensions

Weight	3400 g
Dimensions (WxDxH)	475 x 234 x 249 mm
