Securing CA5000/5500/6000/6500 for loading
Securing the CA5000D/PD-CA6500D/PD vibratory
roller from Dynapac for transport.
Direct of travel
Roller loaded in forward
direction
* Lashing 3 can be moved to the rear lashing mount on the roller if necessary.* Lashing 3 can be moved to the rear lashing mount on the roller if necessary.
1 - 4 = double lashings, i.e. one lashing with two parts secured to two different lashing mounts,
symmetrically located on the right and left sides.
1 - 4 = double lashings, i.e. one lashing with two parts secured to two different lashing mounts,
symmetrically located on the right and left sides.
5 = rubber5 = rubber
The lashings' permitted distance interval in metersThe lashings' permitted distance interval in meters
(1 - 4: Double lashings, LC at least 1.7 tonnes (1700 daN), S
TF
300 kg (300daN))(1 - 4: Double lashings, LC at least 1.7 tonnes (1700 daN), S
TF
300 kg (300daN))
Double L
1
Double L
2
Double L
3
Double L
4
Double L
1
Double L
2
Double L
3
Double L
4
1,1 - 2,5 0,9 - 2,5 1,1 - 2,5 0,2 - 2,51,1 - 2,5 0,9 - 2,5 1,1 - 2,5 0,2 - 2,5
For lashing 1 is L
1
the distance between the lashing point on the edge of the platform and the point directly sideways
from the lashing point on the roller perpendicular to the platform edge.L
2
- L
4
The relationship for lashings 2 - 4 is the
same.
For lashing 1 is L
1
the distance between the lashing point on the edge of the platform and the point directly sideways
from the lashing point on the roller perpendicular to the platform edge.L
2
- L
4
The relationship for lashings 2 - 4 is the
same.
