Fayat Group DYNAPAC CA5000 - Dimensions, Side View

Technical specifications
4812158701_G.pdf 2019-10-01
Dimensions, side view
Dimensions mm inDimensions mm in
A Wheelbase, drum and wheel 3100 122A Wheelbase, drum and wheel 3100 122
L Length, standard equipped roller 6240 246L Length, standard equipped roller 6240 246
H Height, with ROPS/cab 2890 114H Height, with ROPS/cab 2890 114
D Diameter, drum (D)D Diameter, drum (D)
CA5000 1536 60.5CA5000 1536 60.5
CA5500, CA6000, CA6500 1546 60.9CA5500, CA6000, CA6500 1546 60.9
D Diameter, drum (PD) 1518 59.8D Diameter, drum (PD) 1518 59.8
S Thickness, drum amplitude, Nominal (D)S Thickness, drum amplitude, Nominal (D)
CA5000 43 1.7CA5000 43 1.7
CA5500, CA6000, CA6500 48 1.9CA5500, CA6000, CA6500 48 1.9
S Thickness, drum amplitude, Nominal (PD) 34 1.3S Thickness, drum amplitude, Nominal (PD) 34 1.3
P Height, pads (PD) 102 4.0P Height, pads (PD) 102 4.0
K1 Clearance, tractor frame 450 18K1 Clearance, tractor frame 450 18
K2 Clearance, drum frame 450 18K2 Clearance, drum frame 450 18
