Operation
4812158701_G.pdf 2019-10-01
Belt reminder
The machine can be equipped with seat belt with belt
reminder.
Unless the seat belt is used, a warning image appear
in the display and a warning buzzer sounds to alert the
driver to use the seat belt.
Operator's seat, comfort - Adjustments
6
4
2
1
3
5
Fig. Operator’s seat
1. Lever - length adjustment
2. Wheel - height adjustment
3. Wheel - seat cushion inclination
4. Wheel - backrest inclination
5. Wheel - armrest inclination
6. Wheel - lumbar support adjustment
Adjust the operator's seat so that the position is
comfortable and so that the controls are within easy
reach.
The seat can be adjusted as follows:
- Length adjustment (1)
- Height adjustment (2)
- Seat-cushion inclination (3)
- Backrest inclination (4)
- Armrest inclination (5)
- Lumbar support adjustment (6)
Always ensure that the seat is locked in position
before operating the roller.
Always ensure that the seat is locked in position
before operating the roller.
60
