Technical specifications
4812158701_G.pdf2019-10-01
Dimensions, top view
Dimensions mm inDimensions mm in
B1 Width, standard equipped rollerB1 Width, standard equipped roller
CA5000, CA5500, CA6000 2340 92CA5000, CA5500, CA6000 2340 92
CA6500 2380 94CA6500 2380 94
B2 Width, tractor section 2130 84B2 Width, tractor section 2130 84
O1 Overhang, left frame sideO1 Overhang, left frame side
CA5000, CA5500, CA6000 105 4.1CA5000, CA5500, CA6000 105 4.1
CA6500 125 4.9CA6500 125 4.9
O2 Overhang, right frame sideO2 Overhang, right frame side
CA5000, CA5500, CA6000 105 4.1CA5000, CA5500, CA6000 105 4.1
CA6500 125 4.9CA6500 125 4.9
R1 Turn radius, external 5800 228R1 Turn radius, external 5800 228
R2 Turning radius, inner 3300 130R2 Turning radius, inner 3300 130
W Width, drum 2130 84W Width, drum 2130 84
17
