Operation
4812158701_G.pdf 2019-10-01
Display symbol Sound Soot
level
Comment "Yellow
warning"
Display symbol Sound Soot
level
Comment "Yellow
warning"
>100% This view appears after an active selection in
the display screen.
>100% This view appears after an active selection in
the display screen.
Beep >=100% Normal burnout is taking place; if possible do
not turn off the machine until burnout is
complete, approx. 25 min. or 100% reached.
Flashes for a
few seconds,
then lights
continuously
for 2 min.
Beep >=100% Normal burnout is taking place; if possible do
not turn off the machine until burnout is
complete, approx. 25 min. or 100% reached.
Flashes for a
few seconds,
then lights
continuously
for 2 min.
Long beep >100% Burnout delayed due to low engine
temperature.
The temperature of the engine must be above
70°C before burnout can start.
0.5HzLong beep >100% Burnout delayed due to low engine
temperature.
The temperature of the engine must be above
70°C before burnout can start.
0.5Hz
Burnout delayed due to other engine fault.Burnout delayed due to other engine fault.
Long beep >=114% One of the stipulated requirements is not
satisfied and burnout is delayed.
Engine temperature below 70°C.
1HzLong beep >=114% One of the stipulated requirements is not
satisfied and burnout is delayed.
Engine temperature below 70°C.
1Hz
Other engine faultOther engine fault
>=114% "Keep engine running" is displayed if burnout
is in progress or if there is a delay due to low
engine temperature or other engine fault.
Allow the engine to run until burnout is
complete.
>=114% "Keep engine running" is displayed if burnout
is in progress or if there is a delay due to low
engine temperature or other engine fault.
Allow the engine to run until burnout is
complete.
Buzzer >125% The engine's output is reduced by 30% and
vibration may stop working.
Allow the engine to run until burnout is
complete.
1HzBuzzer >125% The engine's output is reduced by 30% and
vibration may stop working.
Allow the engine to run until burnout is
complete.
1Hz
>143% "Red warning" flashes on the panel. The
engine's output is reduced by 30% and max.
1200 rpm.
DEUTZ service must be contacted
1Hz>143% "Red warning" flashes on the panel. The
engine's output is reduced by 30% and max.
1200 rpm.
DEUTZ service must be contacted
1Hz
72
