21
Chapter "Usage"
B
A
B
A
3. Check the drivepack makes a tight fit.
If the drivepack does not lock, repeat the procedure. Do not use the
drive system if the drivepack cannot be locked to the eBike.
4.1.3 Remove drivepack from eBike
More detailed information can be found → in chapter 15.2 "Remove drivepack from
e-bike".
1. Secure the drivepack with one hand.
2. Press the push button or move the locking lever upwards as far as
possible to release the drivepack from the lock.
3. Press and hold the push button and carefully lower the drivepack.
The locking lever automatically remains in the open position.
4. Remove the drivepack from the interface on the bottom bracket.
B
A
B
A
4.1.4
