Chapter "Model variants of the remote"
REMOTE
19 MODEL VARIANTS OF THE REMOTE
Depending on the model, you operate your drive system using the model "b"
remote or the model "fX" remote.
Since the model variants differ both visually and in their handling,
the models within this section are described separately in Chapters 20–23
(Model "b") and 24–27 (Model "fX").
► Note the chapters 20–23 within this section - if your e-bike is equipped
with the "b" model remote.
or
► Note the chapters 24–27 within this section - if your e-bike is equipped
with the model "fX" remote.
20 DETAILED VIEW & PART DESIGNATIONS:
REMOTE "b" MODEL
2
1
3
4
C
6
5
