Chapter "Using drivepack"
42
15.2 Remove drivepack from e-bike
CAUTION
Risk of burns!
The radiator in the drivepack can become very hot during
operation so that you can burn yourself on it.
► Let the drivepack to cool down completely before touching
the drivepack.
If you press the drivepack firmly against the frame before
pressing the push button or releasing the locking lever, it will
be easier to release the drivepack from the locking device on
the frame when removing it.
1. Secure the drivepack with one hand.
2. Press the push button down with the other hand to release the drivepack
from the lock.
or
Move the locking lever upwards as far as possible to release the
drivepack from the lock.
3. Press and hold down the push button and carefully lower the drivepack
out of its holder in the down tube.
The locking lever automatically remains in the open position.
4. Remove the drivepack from the front of the interface on the bottom
bracket.
