FAZUA Evation - Charger; 32 Detailed View & Part Designations: Charger

73
Chapter "Detailed view & part designations: Charger"
CHARGER
32 DETAILED VIEW & PART DESIGNATIONS:
CHARGER
6
7
1 2
4
8
Model "DZL"
5
3
8
1
3
2
4
6
7
Model "STC"
E
Part designations
1
→
Mains adapter
2
→
Charging cable
3
→
Charging plug
4
→
Mains cable
5
→
Mains plug (power supply)*
6
→
Plug
7
→
Mains socket
8
→
LED display
* Different from country to country, therefore without illustration.

The numbering 1–8 within this section refers to the individual
parts of the components
E
(charger).
Individual parts of other components illustrated within this
section are additionally marked with the corresponding
component letter.
