57
Chapter "Technical data model "fX""
Part designations
1
→
Upper touch sensor
2
→
Center button
3
→
Lower touch sensor
4
→
LED display
5
→
Brightness sensor
6
→
Display of charging level/support level
7
→
Status display
The numbering 1–7 within this section refers to the individual
parts of the components
C
(remote).
Individual parts of other components illustrated within this
section are additionally marked with the corresponding
component letter.
25 TECHNICAL DATA MODEL "fX"
TECHNICAL DATA ON THE REMOTE
Article numbers
→
5002000301
5002000302
Degree of protection (in assembled
condition)
→
IP54
Weight, approx.
→
0.088 lbs (0.040 kg)
Operating temperature
→
14 °F to 140 °F (-10 °C to +60 °C)
Storage temperature
→
-4 °F to 140 °F (-20 °C to +60 °C)
26 DISPLAY ON "fX" MODEL
The LED display on the remote consists of 5 LEDs.
• All five LEDs together serve as a display for the charge level and
the support level of the pedal support.
• The upper of the five LEDs also serves as a status indicator,
informing you about the status of your e-bike.
