MT86/MT86HT Flow Meter APPENDIX D – CE CONFORMANCE
Fluid Components International LLC 47
APPENDIX D CE CONFORMANCE
APPROVED CE MARKING CONFIGURATIONS
Approved Options
1. All process temperature ranges
2. All metallic sensor elements
3. All process connections and flanges
4. All insertion U-lengths
5. Aluminum and 300 series stainless steel NEMA 4X local and remote enclosures
6. All specified application combinations
7. All cable jackets and lengths
8. 115/230 VAC input power
Approved Part Numbers
MT86 &
MT86HT
1-20 21 22-40
BCDE
All options conform to CE marking requirements.
X or Y options only conform to CE marking.
All other configurations must be approved for CE marking conformity by FCI's engineering department.
CONDITIONALLY APPROVED CE MARKING CONFIGURATIONS
24 VDC Factory Selectable Option
The models included in this family may be factory selected for input power of 24 VDC. Since the manufacturer does not supply the power
source or transformer for these connections, the responsibility for the conditioning of these sources and associated compliance to the EMC
Directive shall be the responsibility of the User.
Panel Mounted Control Circuit Options
Input power of 24 VDC may be optionally selected. Sense the manufacturer does not supply the power source for these connections, the
responsibility for the conditioning of these sources and associated compliance to the EMC Directive shall be the responsibility of the user.
INSTALLATION CONFORMITY CRITERIA
Grounding
All enclosures must be grounded to earth ground through a path of less than 1 ohm.
Interconnecting Cables
All interconnecting cables between the instrument's local enclosure, remote enclosure, power source and mounting device shall be
enclosed in metal conduit. AC power input cabling shall be enclosed separately in conduit before entrance into the instrument and is not to
be combined with switch or monitor output cabling.
