Chapter 6 Description of Operations
PAGE 6-41
D-No.010 controller Maximum Current Cannot be changed
This indicates the maximum current value of the controller.
D-No. 011 IP Address (upper 6 digits) D-No. 012 IP Address (lower 6 digits)
Setting range: 0 ～ 255
The IP address is set here.
D-No. 013 Subnet Mask (upper 6 digits) D-No. 014 Subnet Mask (lower 6 digits)
Setting range: 0 ～ 255
The subnet mask is set here.
D-No. 015 Default Gateway (upper 6 digits) Setting range: 0 ～ 255
D-No. 016 Default Gateway (lower 6 digits) Setting range: 0 ～ 255
The default gateway is set here.
･ After being changed, the settings of D-Nos. 011 ～ 016 are made available by
reactivation of the control power.
･Please execute the reactivation of the control power after confirming that the “ProG”
indication on the upper stage of the indicator changes from being lit up to being unlit
after changing the setting.
・If the control power is turned OFF while “ProG” lights up, the parameters may become
initialized.
D-No. 017 MAC Address (upper 6 digits) D-No. 018 MAC Address (lower 6 digits)
Cannot be changed
The MAC address is indicated.
D-No. 019 RTC: Year/Month/Day Setting range: 13～99 (year), 1～12 (month), 1～31 (day)
D-No. 020 RTC: Time Setting range: 0 ～ 23 (hours), 0 ～ 59 (minutes), 0 ～ 59 (seconds)
The date and time of the RTC are indicated. The range for the year is 2013 ～ 2099.
* This is not indicated at a SLAVE Axis of the multi system.
D-No. 021 Erase Fastening Record/Format CF Card
Erasure of the fastening result record is executed. Please refer to “Copying of Parameters and
Erasure of the Fastening Result Record” regarding the method for erasing the fastening result record.
Also, if the Expansion controller 2 (Model: MFC-CF) is installed, formatting of the CF card can be
executed. Please refer to “Formatting the Memory Card” regarding the method for formatting the CF
card.
D-No. 022 Parameter Copy
Copying of parameters is performed. Please refer to “Copying of Parameters and Erasure of the
Fastening Result Record” regarding the method for copying parameters.
D-No.023,024,025,028,029 For Adjustment by the Manufacturer
Not used.
