Chapter 6 Description of Operations
PAGE 6-43
System Parameters (Options)
D-No.033 System Option 1 Standard setting: 000000
Optional functions of the controller are set here.
*****1: Accept Relay output (0:level/1:pulse)
・Set to “1” if the QL-OK output signal of the standard IO is to be in pulse form.
****1*: Total Accept Relay Output (0:level/1:pulse)
・Set to “1” if the TOTAL-OK output signal of the standard IO is to be in pulse form.
***1**: Accept Relay Output Timing(0:300msec/1:800msec)
・If the pulse method has been selected, select the pulse length here.
**1***: Stop input (0: Open Stop/1: Close Stop)
・Set to “1” if the logic of the STOP input signal is to be set to the B contact.
*1****: Self check (0: Startup Time /1: only the first cycle)
・Set to "1" to perform the CAL check at the fastening start only in the first cycle.
Except when a judgment other than the one of the ACCEPT axis is made in the first cycle,
the CAL check is performed at the next fastening start, too.
1*****: ID input selection (0:Fieldbus/1:RS232C-3)
・For selecting whether the ID data are to be input as a fieldbus message or input in the RS232C-3
port.
