Chapter 6 Description of Operations
PAGE 6-11
●List of Contents Indicated in the Fastening Result Mode
WORK
COUNT
/D-NO
DATA
controller
r01～r64
c##
Peak torque H/L
N • m
01
Final angle H/L
Deg
02
Rate 1 H/L
N • m/deg
03
Rate 2 H/L
N • m/deg
04
Rate 3 H/L
N • m/deg
05
1st timeH/L
Sec
06
2nd time H/L
Sec
07
Cycle time
Sec
08
Differential angle H/L
Deg
09
Axis judgment
reject: REJECT (fastening NG (fail))
accept: ACCEPT (fastening OK)
abn: Stoppage due to ABNORMAL (error occurrence) signal
stop: Stoppage due to STOP (emergency stop) signal
reset: System cleared by RESET signal
bypass: Stopping due to BYPASS signal
st-off: START signal set to OFF during output of BUSY (operating) signal
10
1st NG item *The D-No. of the fastening NG (fail) item that occurred first is
indicated.
11
Rate 1/2/3 judgment H/L
12
Fastening method … trq: torque method, ang: angle method
13
Number of fastening steps … 1 step, 2 steps, 3 steps
14
Self-checking flag (SC) … ON: self-checking performed
OFF: self-checking not performed
15
Reverse flag (RV) … ON: reverse rotation performed
OFF: reverse rotation not performed
16
Servo lock flag (SL) … ON: servo lock performed
OFF: servo lock not performed
17
1st peak torque
N • m
18
2nd peak torque
N • m
19
Snug torque H
N • m
20
Final torque H/L
N • m
21
Rate 1 increment torque (torque from start of rate 1 to end of rate 1)
N • m
22
Rate 1 increment angle (angle from start of rate 1 to end of rate 1)
Deg
23
Rate 2 increment torque (torque from start of rate 2 to end of rate 2)
N • m
24
Rate 2 increment angle (angle from start of rate 2 to end of rate 2)
Deg
25
Rate 3 increment torque (torque from start of rate 3 to end of rate 3)
N • m
26
Rate 3 increment angle (angle from start of rate 3 to end of rate 3)
Deg
27
Peak current H/L (current high/low limit warning indication)
N • m
28
Rundown revolutions H/L
rev.
29
Load rate
%
30
Current value at stopping of fastening
A
31
------ indication
32
Axis cycle count (×1 million) * “--" if less than 1 million cycles
33
Axis cycle count (×1)
34
Tool cycle count (×1 million) * “--" if less than 1 million cycles
35
Tool cycle count (×1)
36
ACCEPT COUNT *0 to cycle count (0 to 99)
This DATA indication is always performed as [c##] for COUNT/D-No. 00.
NG (failure) result indication is performed for COUNT/D-No. 00 to 10.
