82
Component Bolted connection Shimano* Campagnolo** SRAM ***
Nm Nm Nm
Brake levers Bolt of fastening clamp (Allen bolt) 6-8 5-7
(Rim brakes) Mounting bracket bolt (screwdriver) 2.5-3
Hub Quick-release lever 5-7.5
Locknut for adjustment of quick-release hub bearing 10-25
Free-wheel hub Sprocket cluster lock ring 30-50 50 40
Crank set Crank fixing bolt (grease-free square-head) 35-50 32-38
Crank fixing bolt Shimano octalink SRAM GXP 35-50 48-54
Crank fixing bolt Shimano Hollowtech II 12-15
Shaft fixing bolt Campagnolo Ultra Torque 42
Crank fixing bolt Isis 31-34
Crank fixing bolt Gigapipe 48-54
Chain ring bolt 8-11 8 Steel 12-14
Alu 8-9
Sealed cartridge Shimano Hollowtech II 35-50
bottom bracket Campagolo Utra Torque 35
SRAM GXP 34-41
octalink, square-head 50-70 70
Side-pull brake Brake pad fixing bolt 5-7 8 5-7
Cable fixing bolt 6-8 5 6-8
Fixing bolt of brake 8-10 10 8-10
U-Brake Fixing bolt for cable stop on frame 5-7 5.1-6.8
Seat post Fixing bolt of seat clamp ****20-29 22
Pedal Pedal axle 35 31-34
Shoe Cleat bolts 5-6
Spike 4
* According to Shimano information and tech tips
** According to Campagnolo technical specifications
*** SRAM operating instructions
**** These values are reference values
Be sure to also observe the values given in the enclosed manuals of the component manufacturers.
