Component Shimano* Magura** Avid***
Nm Nm Nm
Brake caliper bolt at frame/fork 6-8 6 5-7 (RW)
9-10 (FW)
Brake lever clamp bolt 6-8 4
Single-bolt clamping (Juicy 5) 4-5
Double-bolt clamping (Juicy 7/Carbon) 2.8-3.4
Sleeve nuts on brake lines near lever and normal brake line on caliper 5-7 4 5
Alu-clamping 5
Steel-clamping 7.8
Barbed fittings for brake lines at cable caliper (disc tube) 5-7 6
Cap bolt 0.3-0.5 0.6
Setscrew for bleeder hole 4-6 2.5
Rotor bolts on hub 4 4 6.2
* According to Shimano information and tech tips
** According to Magura manuals
*** SRAM operating instructions
Be sure to also observe the values given in the enclosed manuals of the component manufacturers.
Be sure to always follow the operating instructions of the component
manufacturer when doing any work at the brake system
