FENDT IDEAL Series Workshop Service Manual

Do not do the servicing, examine or adjust chains
or belts while the engine is in operation.
GUID-7D1C9640-D737-4F38-8886-F1D2280DF613-high.jpg [High]
Fig. 36
Do not operate the machine with the drive shaft
shields open or removed. Entanglement in drive
shafts that rotate can cause injury or death.
Stay clear of components that rotate.
Make sure that guards that rotate can rotate freely.
A loose yoke can come o a shaft and result in
injury to persons or damage to the machine.
When you install a quick disconnect yoke, the
spring activated locking pins must move freely and
be in the groove on the shaft. Pull on the driveline
to make sure that the quick disconnect yoke can
not be pulled o the shaft.
GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High]
Fig. 37
Remove spilled oil, antifreeze or fuel immediately
from the steps, platform, and other access areas.
Keep all access areas clean of unwanted materials.
GUID-3B306DB1-0777-4FA6-86F1-895652B4C1DB-high.jpg [High]
Fig. 38
1. General
1-26 IDEAL Series Combine
79037318C
