1.3.30.3 Lubrication points, left side
GUID-84451417-C12F-46B5-8B22-D35482AE53A0-high.jpg [High]
Fig. 61
Lubrication points on the left side of machine and hours of operation between lubrication.
1.3.30.4 Break Glass - Exit
Break glass - Exit
Break glass in case of an emergency exit.
Exit cab.
1.3.30.5 Lift point
Lift point
The lift symbol identifies an approved lift point on
the machine.
GUID-10FE06E3-DDC6-4940-AF0B-2CEA0EDE888D [V1]
GUID-CEDA25AA-DAEB-4CE6-9C89-4A47D8172618 [V1]
GUID-2216EA63-D26D-4CD6-BF05-EC62BD648FD9 [V1]
