FENDT IDEAL Series Workshop Service Manual

Filters
IDEAL 7 IDEAL 8 IDEAL 9
Top tank fil ter 11 micron
Hydrostatic boost filter 9 micron
Suction strainer filter 150 micron
Active tailboard/Straw spreader 18 micron
1.4.11 Climate control specifications
Air conditioning IDEAL 7 IDEAL 8 IDEAL 9
Refrigerant type R134A
Refrigerant capacity 2.4 kg (5.3 lb)
Refrigerant oil type PAG 46
Refrigerant oil capacity 300 cc (10.1 ounce)
Air conditioning IDEAL 7 IDEAL 8 IDEAL 9
Fresh filter CAT2
Recirculation filter
1.4.12 Compressed air specifications
Compressed air system IDEAL 7 IDEAL 8 IDEAL 9
Tank size 60 l (15.8 gal)
Maximum pressure 9.5 bar (138 psi)
Compressor lubrication Shared with engine
1.4.13 Machine drive specifications
Ground drive
IDEAL 7 IDEAL 8 IDEAL 9
Description 2-speed ground drive transmission, synchronized ranges and dierential
lock
Input flange Dual flange for hydraulic motor with 4-bolt SAE D or E mounting flange
per ISO 3019/1
Input shaft Splined shaft per ANSI 92.1, 27 teeth 16/32 DP
Output shaft Splined shaft B50x45 per DIN 5482, 24 teeth, module 2, 30° pressure
angle
Field gear ratio 42/20 to 1
Road gear ratio 27/35 to 1
Dierential gear ratio 66/19 to 1 64/21 to 1
4
GUID-865A6544-A74F-4D1D-8134-80AF4DB6D6B4 [V3]
GUID-4BB43A65-7118-4486-91BD-B792DA48303D [V2]
GUID-5A2CF7FA-5282-44A3-B630-DEF56A481C60 [V3]
1. General
IDEAL Series Combine 1-73
79037318C
