1.3.30.22 Burn hazard - hot surface
Burn hazard - hot surface
Burn hazard - hot surface.
Stay clear and do not touch the hot surfaces.
1.3.30.23 Impact hazard, coiled spring, variator
Impact hazard
Impact hazard - coiled spring.
Make sure the coiled spring in the variator cannot
move before you repair or lubricate the variator.
1.3.30.24 Jack point
Jack point
CMGHE0110211501
Original art: /m/TECHNICL/_MASSEY/Hesston/OpMan/2370 UHD LSB/Information/Decals/700745037_rev1.pdf
Shows the location to put a jack
1.3.30.25 No step
No step
The no step symbol identifies a location where you
must not walk.
GUID-2A1B4E6D-F1E9-4729-BF9A-D361D0E61491 [V2]
GUID-156F2BEA-EBC4-452B-8DCE-F918552C885E [V1]
GUID-52DDD595-9541-4EF8-88B2-3D64B225377E [V1]
GUID-EE5948EB-B63C-4305-BF77-40BC653EC654 [V1]
1. General
IDEAL Series Combine 1-41
79037318C

FENDT IDEAL Series Specifications

General

Category	Combine Harvester
Manufacturer	Fendt
Series	IDEAL
Engine Type	MAN diesel engine (various models)
Max Speed	40 km/h
Fuel Tank Capacity	1250 liters
Tire Options	Various sizes and types available
Cab Features	Air-conditioned, ergonomic design, multifunctional armrest, touchscreen display
Technology	Fendt Connect (telemetry), guidance systems, yield mapping
Unloading Rate	140 - 210 l/s (depending on model)
Cab	Fendt Vision Cab
Tracks	Available on some models (TrakRide)
