1.4.8 Electrical specifications
Electrical IDEAL 7 IDEAL 8 IDEAL 9
Type 12-volt, negative ground (24-volt starting)
Alternator 320 amp
Batteries Four 12-volt, top post, 1000 cold cranking amp
1.4.9 Machine lamp specifications
Machine lamps IDEAL 7 IDEAL 8 IDEAL 9
Headlamps / main beam Two halogen lamps on the cab, lower valence
Headlamps / dipped beam Two halogen lamps on the cab, lower valence
Front position lamp Two in the front
End outline marker lamp, front/
rear
Two white / red lamps on the front
Direction indicator lamp, front Two amber lamps on the front
Direction indicator lamp, side Two amber lamps on the side
Direction indicator lamp, rear Two round amber lamps at the rear
Combination stop / tail Two round red lamps at the rear
Registration plate lamp Two lamps at the rear
Beacon, front Two amber lamps on the cab roof
Beacon, rear One amber lamp on the rear rail
Unloader stop / tail One amber lamp on the unloader
Forward facing, long range Two halogen lamps on the cab, upper valence
Forward facing, short range Six halogen lamps on the cab, upper valence
Stubble lamp, inboard Two halogen lamps on the cab, under the lower valence
Work lamp, maintenance Two lamps under the shield on the primary side
Rear facing, short range Two halogen lamps at the rear
Rowfinder lamp Two halogen lamps, on the side shield, forward, inset
Rear ladder One halogen lamp at the rear ladder
Work lamp, engine One halogen lamp under the engine cover
Grain tank One LED lamp on the forward grain tank extension
Unloader One LED lamp forward of the unloader chute
Entry / Egress lamps Six LED lamps on the cab ladder / stairs
Portable work lamp, cordless One lamp on the entry platform
GUID-0E596D5E-029F-47F0-ACD4-DA020E2E5271 [V3]
GUID-B1EF3599-8BF3-411C-B8E7-4403C79E7991 [V2]
1. General
IDEAL Series Combine 1-71
79037318C
