FENDT IDEAL Series Workshop Service Manual

1.3.30.14 12V/120W
12V/120W
The machine is equipped with a 12 volt electrical
system.
1.3.30.15 Main fuses
Main fuses
Shows fuses used for main components.
1.3.30.16 Telescopic deck handrail
Telescopic deck handrail
Lift the telescopic deck handrail and twist counter
clockwise to lock into place. Lift the telescopic deck
handrail and turn clockwise to lower back into the
stowed position.
1.3.30.17 Unloader drive
Unloader drive
Leave a 1 mm to 2 mm space between the nut and
unloader drive hub.
GUID-E424B01C-EDEB-4DF0-AB6A-5682989F1F66 [V1]
GUID-4433076D-6568-4A4E-A50E-A7929C80CA94 [V1]
GUID-3756116C-62D3-4A9D-AC95-8707A1ABF90D [V1]
GUID-8DF87133-A208-4EE0-8AA0-39F57D473BCD [V1]
1. General
IDEAL Series Combine 1-39
79037318C
