FENDT IDEAL Series Workshop Service Manual

1.4.15 Brake specifications
Brakes
IDEAL 7 IDEAL 8 IDEAL 9
Service brakes Left/right, wet multidisc with ball ramp actuation, non-boosted slave cylinders
and DOT 4 brake fluid in combination with hydrostatic
Location Transmission output shaft
Park brake Spring apply hydraulic release cylinder with push-pull cable, cable breakage
indicator and valve for controlled emergency braking
1.4.16 Wheel torque specifications
Front wheels
IDEAL 7 IDEAL 8 IDEAL 9
Wheel to final drive
flange
900 Nm (665 lbf ft)
Inner dual to outer dual 900 Nm (665 lbf ft)
Rear wheels
IDEAL 7 IDEAL 8 IDEAL 9
Standard rear axle (wheel
to hub)
750 Nm (550 lbf ft)
Rear wheel assist axle
(wheel to drive motor
flange)
750 Nm (550 lbf ft)
GUID-A37DAF53-EAF3-4E42-BBC0-74D9F24A0DFA [V3]
GUID-4296D2BF-8AD0-4F78-B91D-F527CA32567D [V3]
1. General
IDEAL Series Combine 1-75
79037318C

FENDT IDEAL Series Specifications

General

Category	Combine Harvester
Manufacturer	Fendt
Series	IDEAL
Engine Type	MAN diesel engine (various models)
Max Speed	40 km/h
Fuel Tank Capacity	1250 liters
Tire Options	Various sizes and types available
Cab Features	Air-conditioned, ergonomic design, multifunctional armrest, touchscreen display
Technology	Fendt Connect (telemetry), guidance systems, yield mapping
Unloading Rate	140 - 210 l/s (depending on model)
Cab	Fendt Vision Cab
Tracks	Available on some models (TrakRide)
