FENDT IDEAL Series Workshop Service Manual

1.3.30.10 Power o delay
Power o delay
Wait at least two minutes after turning o the
machine before disconnecting the battery.
1.3.30.11 Battery positive terminal
Battery positive terminal
The machine is equipped with a 12 volt electrical
system.
WARNING:
Do not jump start a 12 volt system
with a 24 volt power supply. Explosion
hazard can occur causing serious injury
or death.
1.3.30.12 Battery disconnect
Battery disconnect
Battery disconnect switch.
1.3.30.13 Battery negative terminal
Battery negative terminal
Negative terminal for the electrical system.
GUID-724E1361-B727-414D-A1E9-3F34ECCB6900 [V1]
GUID-00AECECC-4F00-4E23-A41F-0B01DF75B8F1 [V1]
GUID-FC0D3A78-15DB-48A6-96E7-A54B69651E4F [V1]
GUID-12D89C05-6FF5-4D13-ADE5-1AA3C9A16716 [V1]
1. General
1-38 IDEAL Series Combine
79037318C
