FENDT IDEAL Series Workshop Service Manual

Ground drive
IDEAL 7 IDEAL 8 IDEAL 9
Overall field ratio 7.2948 to 1 6.4 to 1
Overall road ratio 2.6796 to 1 2.351 to 1
Lubrication Mix of splash and pressure system with suction strainer and pressure
filter with clogging indicator
Wheel final drive
IDEAL 7 IDEAL 8 IDEAL 9
Description 2-stage (spur + planetary) wheel final drive
Overall ratio 12.183 to 1, with a first stage ratio of 82/21 to 1
Input shaft Splined shaft, 24 teeth, module 2, 30 deg. pressure angle, according to
DIN5482
Wheel flange 335 mm (13.1 in) bolt circle diameter, 280.8 mm (11.1 in) pilot diameter,
20x M24x3
Transmission
IDEAL 7 IDEAL 8 IDEAL 9
Type Sychronized ranges and dierential lock
Speeds Two
Ground speed
IDEAL 7 IDEAL 8 IDEAL 9
Field mode - low gear 15 km/h (9.3 mph)
Field mode - high gear 15 km/h (9.3 mph)
Transport mode - low gear 15 km/h (9.3 mph)
Transport mode - high gear 40 km/h (24.8 mph)
[1]
[1]
Limited to local maximum speed.
1.4.14 Steering specifications
Axle types
IDEAL 7 IDEAL 8 IDEAL 9
Standard axle Adjustable
Optional axle Adjustable, rear wheel assist (RWA)
Tread settings
IDEAL 7 IDEAL 8 IDEAL 9
Standard axle 3.3 m to 3.9 m (130 in to 154 in)
Optional axle 3.3 m to 3.9 m (130 in to 154 in)
Adjustment increments 150 mm (6 in)
GUID-2E37DA51-A7E4-40E2-8BBD-5F0BCE1AA5A9 [V2]
1. General
1-74 IDEAL Series Combine
79037318C

FENDT IDEAL Series Specifications

General

Category	Combine Harvester
Manufacturer	Fendt
Series	IDEAL
Engine Type	MAN diesel engine (various models)
Max Speed	40 km/h
Fuel Tank Capacity	1250 liters
Tire Options	Various sizes and types available
Cab Features	Air-conditioned, ergonomic design, multifunctional armrest, touchscreen display
Technology	Fendt Connect (telemetry), guidance systems, yield mapping
Unloading Rate	140 - 210 l/s (depending on model)
Cab	Fendt Vision Cab
Tracks	Available on some models (TrakRide)
