IDEAL 9 Wheels ParaLevel Tracks
Total 20 770 kg (45 790
lbs)
21 620 kg (47 664 lbs) 24 385 kg (53 760 lbs)
Front 10 280 kg (22 663 lbs) 11 150 kg (24 582 lbs) 13 960 kg (30 776 lbs)
Rear 10 490 kg (23 126 lbs) 10 470 kg (23 082 lbs) 10 425 kg (22 983 lbs)
These masses (weights) have a tolerance of +/- 2%.
Optional equipment can increase the mass (weight) up to 10%
These masses (weights) for a machine with:
• 75 kg (165 lb) operator
• No header
• Empty grain tank
• Straw chopper
• Full fuel tank
• Full DEF tank
• Front tires 800/70R38
• Rear tires 620/75R26
• Not rear wheel assist (RWA)
RWA machines: Add 475 kg (1047 lb) to total mass (weight) and to the rear mass (weight).
3rd axle: Add 135 kg (298 lb) to total mass (weight).
NOTE: The weights in the table below refer to the Italian approval and are displayed on the respective
approvals tag; for all other countries, check the maximum permitted weights displayed in the vehicle
registration documents or on the manufacturer plate.
Italy - Maximum weight permitted on public roads
IDEAL 9 Wheels Tracks
Total 24 600 kg 27 400 kg
Front 13 700 kg 14 800 kg
Rear 12 300 kg 12 500 kg
Maximum towed mass
• Trailer without brakes: 3500 kg - maximum vertical load 200 kg
• Trailer with inertia brakes: 6000 kg - maximum vertical load 200 kg
1.4.3 Tire specifications
Use the maximum tire pressure allowed by the tire manufacturer.
The specifications in this section are approximate and can vary depending on the machine type and
harvesting conditions.
GUID-3EBB5789-2AAF-4DE7-B390-3ECB4AF6FCD8 [V2]
1. General
IDEAL Series Combine 1-61
79037318C
