FENDT IDEAL Series Workshop Service Manual

Cha spreader, if
equipped
IDEAL 7 IDEAL 8 IDEAL 9
Type 2 radial rotating discs, adjustable speed, and adjustable spout position
Drive Hydraulic
Straw spreader, if
equipped
IDEAL 7 IDEAL 8 IDEAL 9
Type 2 radial rotating discs and adjustable speed
Drive Hydraulic
Chopper, if
equipped
High/lo
w
Active/
passive
IDEAL 7 IDEAL 8 IDEAL 9
Type Chopper High - 112 knives plus 55 counter knives options
Low - 56 knives plus 28 counter knives options
Type Tailboard - Active 8 adjustable vanes plus 2 rotating spinners hydraulic
driven with adjustable speed from the cab
- Passive 8 adjustable vanes
Drive Chopper High - Mechanical with a speed of 3600 rpm
Low - Mechanical with a speed of 850 rpm
1.4.7 Cab specifications
General cab IDEAL 7 IDEAL 8 IDEAL 9
Location Centered
Seat Adjustable
Seat (optional) Active heating/cooling system
Seat suspension Pneumatic
Glass type Acoustic laminated. Tempered for the right glass and lef hand door.
Glass area 6.1 m² (66 ft²)
Cab dimensions IDEAL 7 IDEAL 8 IDEAL 9
Glass area 6.1 m² (66 ft²)
Width 1.6 m (63 in)
Mirrors IDEAL 7 IDEAL 8 IDEAL 9
Left hand rear view Convex
Right hand rear view
Front tire auxilary left hand
Front tire auxilary left hand
GUID-C0806682-ECF1-4B51-BA21-7B31FD5BDF70 [V2]
1. General
1-70 IDEAL Series Combine
79037318C

FENDT IDEAL Series Specifications

General

Category	Combine Harvester
Manufacturer	Fendt
Series	IDEAL
Engine Type	MAN diesel engine (various models)
Max Speed	40 km/h
Fuel Tank Capacity	1250 liters
Tire Options	Various sizes and types available
Cab Features	Air-conditioned, ergonomic design, multifunctional armrest, touchscreen display
Technology	Fendt Connect (telemetry), guidance systems, yield mapping
Unloading Rate	140 - 210 l/s (depending on model)
Cab	Fendt Vision Cab
Tracks	Available on some models (TrakRide)
