Cleaning shoe IDEAL 7 IDEAL 8 IDEAL 9
Shoe type Shaker
Shoe width 1350 mm (53.1 in)
Chaer area 2.33 m² (14.5 ft²)
Sieve area 1.08 m² (11.7 ft²)
Ciclone triple cleaning fan IDEAL 7 IDEAL 8 IDEAL 9
Type Radial impeller
Width 1393 mm (54.8 in)
Diameter 445 mm (17.5 in)
Speed 250 rpm to 1400 rpm
Elevators IDEAL 7 IDEAL 8 IDEAL 9
Clean grain elevator type Paddle with an auger for the grain tank fill
Tailings elevator type Auger
Grain tank IDEAL 7 IDEAL 8 IDEAL 9
Type Central fill hopper
Capacity 12500 liter (355 bushel) or 17000 liter (482 bushel)
Streamer (grain
tank unloader)
IDEAL 7 IDEAL 8 IDEAL 9
Type Swivel, hydraulic swing
Unloading rate,
continuous (Per ASAE
spec)
140 liters (4.0 bushel) per second
210 liters (6.0 bushel) per second
Discharge height for
Streamer 140 (140 l/s)
4328.5 mm (170.4 in) to 4637.0 mm (182.6 in)
Discharge height for
Streamer 210 (210 l/s)
4253.9 mm (167.5 in to 4861.6 mm (191.4 in)
Reach with 7.6 m (25
ft) header
2000 mm (78.7 in) 3500 mm (138.9 in) 5000 mm (196.8 in)
Reach with 9.1 m (30
ft) header
1250 mm (49.2 in) 2750 mm (108.3 in) 4250 mm (167.3 in)
Reach with 10.7 m
(35 ft) header
500 mm (19.7 in) 2000 mm (78.7 in) 3500 mm (138.9 in)
Reach with 12.2 m
(40 ft) header
250 mm (9.8 in) 1250 mm (49.2 in) 2750 mm (108.3 in)
Reach with 13.7 m
(45 ft) header
- 500 mm (19.7 in) 2000 mm (78.7 in)
Reach with 15.2 m
(50 ft) header
- <250 mm (9.8 in) 1250 mm (49.2 in)
Reach with 16.8 m
(55 ft) header
- - 500 mm (19.7 in)
1. General
IDEAL Series Combine 1-69
79037318C
