FENDT IDEAL Series Workshop Service Manual

Final drives - wheels
IDEAL 7 IDEAL 8 IDEAL 9
Quantity 11 L (11.6 qt)
Type AGCO SAE 80W-90 gear oil
Type - EME
Fendt Super Trans 85W-90
AGCO Parts Axle Oil LS 80W-90
Final drives - tracks
IDEAL 7 IDEAL 8 IDEAL 9
Quantity 5 L (5.3 qt)
Type AGCO SAE 80W-90 gear oil
Type - EME
Fendt Super Trans 85W-90
AGCO Parts Axle Oil LS 80W-90
Dierential - RWA
IDEAL 7 IDEAL 8 IDEAL 9
Quantity 13.1 L to 14.5 L (13.8 qt to 15.3 qt)
Type AGCO SAE 80W-90 gear oil
Type - EME
Fendt Super Trans 85W-90
AGCO Parts Axle Oil LS 80W-90
Hubs - RWA
IDEAL 7 IDEAL 8 IDEAL 9
Quantity (each hub) 1.6 L to 1.8 L (1.7 qt to 1.9 qt)
Type AGCO SAE 80W-90 gear oil
Type - EME
Fendt Super Trans 85W-90
AGCO Parts Axle Oil LS 80W-90
1.4.6 Machine system specifications
Threshing unit IDEAL 7 IDEAL 8 IDEAL 9
Type Single helix (rotor) Dual helix (rotor)
Length 4814 mm (189.5 in)
Diameter 690 mm (27.2 in)
Concaves Small grain, large grain, round bar
Concave area (each rotor) .83 m² (8.9 ft²) 1.66 m² (17.9 ft²)
Separating area (each rotor) 1.44 m² (15.5 ft²) 1.92 m² (20.7 ft²) 2.40 m² (25.8 ft²)
Total threshing and separating
area (each rotor)
2.27 m² (24.4 ft²) 3.58 m² (38.5 ft²) 4.06 m² (43.7 ft²)
