FENDT IDEAL Series Workshop Service Manual

Tracks - track/tire combinations
Front Rear
520/80 R26 620/70 R26 750/65 R26
26 x
30 x x
36 x x x
NOTE: X = only possible combination
Rear tires
Tire size Load
index
Tire load
capacity at 15
km/h (9 mph)
Tire load
capacity at 40
km/h (25 mph)
Index
radius
Rim size Oset Max
width
520/80
R26
168A8 7450 kg (16424
lbs)
5600 kg (12346
lbs)
700 DW16Ax2
6
- 5 mm (-
0.2 in)
3290 mm
(144.9 in)
620/70
R26
173A8 8650 kg (19070
lbs)
6500 kg (14330
lbs)
725 DW20Bx2
6
- 5 mm (-
0.2 in)
3490 mm
(144.9 in)
750/65
R26
166A8 8215 kg (18111
lbs)
5300 kg (11684
lbs)
750 DW25Bx2
6
- 5 mm (-
0.2 in)
3680 mm
(144.9 in)
[1]
[1]
For track machines: 3790 mm (149.2 in)
1.4.4 Engine specifications
Engine
IDEAL 7 IDEAL 8 IDEAL 9
Engine manufacture AGCO Power Inc. MAN Truck & Bus AG
Engine type 98 LFVC-D5.1352 D2676LE145 D3876LE126
Capacity (cm³) 9822 12419 15256
Aspiration Turbocharged
Rated power at 1900 rpm 292 kW (392 hp) 351 kW (470 hp) 421 kW (564 hp)
Rated boost at 1900 rpm 322 kW (432 hp) 388 kW (520 hp) 465 kW (624 hp)
Maximum power at 1750 rpm 336 kW (451 hp) 401 kW (538 hp) 484 kW (649 hp)
Low idle 1000
High idle 1930
Firing order 1-2-4-6-7-5-3 1-5-3-6-2-4 1-5-3-6-2-4
Number of cylinders 7 6
Bore 111 mm (4.37 in) 126 mm (4.96 in) 138 mm (5.43 in)
Stroke 145 mm (5.71 in) 166 mm (6.54 in) 170 mm (6.69 in)
GUID-613F03AE-0B7D-4FB1-B4B5-EDE066691169 [V3]
1. General
1-64 IDEAL Series Combine
79037318C
