WARNING:
Only tires specified by the manufacturer are approved. If non-genuine tires are used, they
must have the same size and strength as the genuine tires. Always use recommended tire
pressure. The tire pressure must be checked with a header attached and lifted from the
ground. The tire inflation pressure is located on the decal on the tire rims.
Use only genuine rims with prescribed tires. Only the prescribed tire and rim combinations
have been approved according to machine weight, width, and speed limits in road
transport.
The wheel rims must comply with local regulations on maximum permissible width on
public roads.
WARNING:
Road transport is allowed only with grain tank empty.
Dual wheels - front tires
Tire size Load index Index radius Rim size Oset Max width
520/85 R42 185A8 925 DW27Bx32 195 mm (7.7 in) 3290 mm (129.5
in)
620/70 R42 184A8 975 DW27Bx38 198 mm (7.8 in) 3290 mm (129.5
in)
710/70 R42 185A8 925 DW27Bx32 105 mm (4.1 in) 3490 mm (137.4
in)
Wheels - front tires
Tire size Load
index
Tire load
capacity at 15
km/h (9 mph)
Tire load
capacity at 40
km/h (25
mph)
Index
radius
Rim size Oset Max
width
800/70
R32
185A8 14340 kg
(31614 lbs)
9250 kg (20393
lbs)
925 DW27Bx3
2
195 mm
(7.7 in)
3290 mm
(129.5 in)
800/70
R38
184A8 13950 kg
(30754 lbs)
9000 kg (19842
lbs)
975 DW27Bx3
8
198 mm
(7.8 in)
3290 mm
(129.5 in)
800/70
R32
185A8 14340 kg
(31614 lbs)
9250 kg (20393
lbs)
925 DW27Bx3
2
105 mm
(4.1 in)
3490 mm
(137.4 in)
800/70
R38
184A8 13950 kg
(30754 lbs)
9000 kg (19842
lbs)
975 DW27Bx3
8
100 mm
(3.9 in)
3490 mm
(137.4 in)
900/60
R32
184A8 13950 kg
(30754 lbs)
9000 kg (19842
lbs)
925 DW27Bx3
2
50 mm
(2.0 in)
3680 mm
(144.9 in)
900/60
R38
184A8 13950 kg
(30754 lbs)
9000 kg (19842
lbs)
975 DW30Bx3
2
50 mm
(2.0 in)
3680 mm
(144.9 in)
1000/55
R32
188A8 15500 kg
(34172 lbs)
10000 kg
(22046 lbs)
875 36.00x32 25 mm
(1.0 in)
4000 mm
(157.5 in)
1. General
1-62 IDEAL Series Combine
79037318C
