3 Commissioning as function module F24
Festo – P.BE-CPX-FB23-24-EN – 1305a – English 45
3.3 Parameterisation
The parameterisation of CPX-Terminal with the bus node CPX-FB23-24 is possible with universal hand-
held (CPX-MMI) and also the PC software Festo Maintenance Tool (CPX-FMT) ( Tab. 3.4) .
General information regarding operation of the handheld and commissioning of the CPX
terminal with the handheld is found in the description of handheld device.
The c urrent version of the PC software CPX Festo Maintenance Tool (CPX-FMT) is found on
the websit e of Fe sto ( www.festo.com).
For the operation of the PC software (CPX-FMT) on the bus node, you need the USB ad-
apter ( c onnecting cable), type N EFC-M12G5-0.3-U1G5.
Warning
The c onnected actuators can move unexpectedly!
Modification of the signal states and parameters with the MMI or CPX FMT c an trigger
dangerous movements of the connected ac tuators.
• Make sure that nobody is in the positioning range of connected actuators and be
very c areful with the parameterisation or manipulation of signal states.
• It is imperative that you observe the instructions on “Force”, “Idle mode” and “Fail
safe” in the CPX system description ( P.BE-CPX-SYS-…) and in the description of the
CPX MMI and in the online help of the CPX FMT.
