3 Commissioning as function module F24
Festo – P.BE-CPX-FB23-24-EN – 1305a – English 47
3.3.2 Parameterisation concepts
The following table includes an overview of the options for parameterisation of the CPX terminal as well
as their advantages and disadvantages.
Method
Description Benefits Disadvantages
Handheld
(CPX-MMI)
Parameterisation is
carried out via
menu-guided entries
with the handheld.
–Comfortable
parameterisation via the
menu navigation (plain
text).
– Parameterisation c an be
saved in the handheld
device.
– Access via remote
maintenance is not
possible.
Festo
Maintenance
Tool (CPX FMT)
Parameterisation via
PC software.
– Very c omfor table
parameterisation via PC
software with
supporting func tions
– Parameterisation c an be
saved on the PC.
– Remote maintenance
via Ethernet possible
1)
.
– PC with connection to
the bus node is
necessary (via USB
2)
or
Ethernet
1)
).
I/O diagnostic
interface
Read-only access to
the current parameters
and data ( CPX
system description).
– It is possible to check
the current parameter
setting by means of the
master.
– The parameters cannot
be modified.
–Expensive
programming.
1) Front end controller (FEC and/or CEC) in CP X terminal required
2) USB adapter (connecting cable), type NEFC-M12G5-0.3-U1G5 ( www.festo.com)
Tab. 3.4 Parameterisation
