1. Installation
1-15
Festo P.BE-CTEU-EC-OP+MAINT-EN en 1208NH
Removal of the DIL switch cover
Note
Observe the following instructions when removing or fit-
ting the cover:
•
Disconnect the power supply before removing the cover.
•
Make sure that the seal is seated correctly when fitting
the cover.
•
Tighten the two mounting screws with a max. torque of
0.4 Nm.
Proceed as follo w s:
1. Switch off the power supply.
2. Unscrew the two mounting screws of the transparent cov-
er and remove the co ver.
