5. Maintenance and conversion
5−40
Festo P.BE−MPA−EN en 0910d
Necessary components
For extension you will require:
Components
Type
One of the following electric MPA supply plates:
 With plug M18, (3−pin)
 With plug 7/8" (4−pin)
 With plug 7/8" (5−pin)
VMPA−FB−SP−V
VMPA−FB−SP−7/8−V−4POL
VMPA−FB−SP−7/8−V−5POL
also a seal without channel separation or a separating seal with
channel separation See chapter 1, Tab.1/8
Tab.5/11: Electrical supply plates
Mounting Proceed as follows:
1. Loosen the electric and pneumatic connections and
remove the MPA−S valve terminal from its fastening
surface (see Chapter 5.2).
2. Mount the electric supply plate as described in the
VMPA−FB−SP−...−V−... assembly instructions.
3. Mount the M PA−S valve terminal onto the fastening
surface (see chapter 2 Mounting onto a wall" or
Mounting onto an H−rail").
4. Then install the pneumatic and electrical connections
(seechapter 3 Installation, connecting the MPA−S
valveterminal").
