1. Summary of components
1−10
Festo P.BE−MPA−EN en 0910d
1
2
3
1
4
3
2
1
Exhaust plate (3/5) or flat plate
silencer
2 Electronic module with LEDs
3 Valves or cover plates
4 Pressure regulator plate (optional)
Fig.1/6: Pneumatic components of the MPA−S valve terminal with CPX terminal or CPI
module, 2nd. level
