1. Summary of components
1−11
Festo P.BE−MPA−EN en 0910d
The MPA−S valve terminal with electric multi−pin or AS
interface consists of the following pneumatic components:
25
3
4
1
4
1
Right end plate
2 Pneumatic supply plate (optional)
3 Inscription labels with support
(optional)
4 Sub−base with work connections and
electric linking
5 Seal (optional isolating seal for
forming pressure zones)
Fig.1/7: Pneumatic components of the MPA−S valve terminal with electric multi−pin or
AS interface, 1st. level
