1. Summary of components
1−32
Festo P.BE−MPA−EN en 0910d
On the pressure regulator plate you will find the following
connecting and operatingelements:
2
1
3
1 Pressure regulator plate MPA2
adjusting screw with free−wheeling and
snap−in locking
2 Pressure gauge (optional)
3 Connection for pressure gauge
(canbeturned 90°)
Fig.1/14: Operating and connection elements of the pressure regulator plates
