1. Summary of components
1−36
Festo P.BE−MPA−EN en 0910d
You will find the following electric connecting elements on the
multi−pin plug connection of the MPA−S valve terminal:
1 Multi−pin plug
cover with cable
2 Connection for
functional earth
3 Sub−D connection
1
2
3
Fig.1/18: Electric connecting elements of MPA−S valve terminal with multi−pin plug
connection
