1. Summary of components
1−37
Festo P.BE−MPA−EN en 0910d
You will find the following display elements on the pneumatic
modules of the MPA−S valve terminal with multi−pin plug
connection or AS interface:
1 MPA1:
Y ellow LEDs:
Signal status
dis pl a y of the pilot
solenoid coils
2 MPA2:
Y ellow LEDs:
Signal status
dis pl a y of the pilot
solenoid coils
3 Label supports
with inscription
field
12 3
Fig.1/19: Electric display elements of MPA−S valve terminal with multi−pin plug
connection or with AS interface
Information on the electric connecting and display elements
of the AS interface can be found in the package insert.
