3. Installation
3−18
Festo P.BE−MPA−EN en 0910d
Proceed as follows:
· Turn the adjusting screw (for position see Fig.3/5) to set
the desired controlled variable (see Flow diagrams of the
pressure regulator valve plates" in Appendi x A).
1 Adjusting screw,
Socket head
(A/F2,0)
1
Fig.3/5: Setting the pressure regulating valve plates (size MPA2) with the aid of the
adjusting screw
